Steel Wire Reinforced Thermoplastics Composite Pipe

Intro

The Steel Wire Reinforced Thermoplastics (PE) Composite Pipe is abbreviated as SRTP, which is a kind of high-strength plastic steel wire wound in the pipe as the reinforcement, and the outer layer and the inner layer are compounded with thermoplastic high-density polyethylene on both sides, which is compounded by extrusion molding method. New environmentally friendly plastic composite pipe. It not only overcomes the respective shortcomings of steel pipes and plastic pipes, but also has excellent pressure-bearing performance of steel pipes and good hygiene performance of plastic pipes.

The steel mesh skeleton polyethylene composite pipe has a three-layer structure, namely the core pipe, the steel wire layer, and the outer PE layer. The core tube and the steel wire winding layer are used to withstand the internal pressure of the pipe, and the outer PE layer is mainly used for welding connection.

Both the core tube and the outer PE layer are made of PE80/PE100 grade raw materials, and the steel wire winding layer is made of HDPE modified material and steel wire. The modified HDPE and HDPE can be melted together under heating conditions.

Applications

• Municipal Engineering:

  urban construction water supply, drinking water, fire fighting water, heat network backwater, gas, natural gas transmission, highway buried drainage and other channels.

• Oil Field and Gas Field:

  oily sewage, gas field sewage, oil and gas mixture, secondary and tertiary oil recovery and gathering and transportation process pipes.

• Chemical Industry:

  acid, alkali, salt manufacturing, petroleum, chemical, fertilizer, pharmacy, textile, printing and dyeing, rubber and plastic industries, process pipes and discharge pipes for conveying corrosive gases, liquids, and solid powders.

• Power Engineering:

  pipelines for process water, return water, water supply, fire fighting water, dust removal, waste residue, etc.

• Metallurgical Mines:

  used for transporting corrosive media and ore slurry, tailings, ventilation pipes and process pipes in non-ferrous metal smelting.

• Seawater Transportation:

  seawater transportation in seawater desalination plants, seaside power plants, and seaport cities.

• Shipbuilding:

  ship sewage pipes, drain pipes, ballast pipes, ventilation pipes, etc.

• Agricultural Sprinkler Irrigation:

  deep well pipes, filter pipes, culvert pipes, drainage pipes, irrigation subordinate camps, etc.

Performance & Advantages

1. Good corrosion resistance

   Compared with metal pipes, steel-framed polyethylene plastic composite pipes, like PE pipes, have excellent chemical corrosion resistance, and have good corrosion resistance to more than 270 corrosive media such as acids, alkalis, salt solutions, and organic solvents.

2. Good anti-wear performance

   The wear resistance of steel frame polyethylene plastic composite pipe is 3 times that of steel pipe

3. Smooth inner wall and low conveying resistance

   The steel skeleton polyethylene plastic composite pipe adopts the internal shaping process, and its inner surface is smoother than the inner wall of the plastic pipe. The equivalent absolute roughness is 0.01mm, while the equivalent absolute roughness of the inner surface of the steel pipe is 0.2mm. The steel pipe has been significantly improved.

4. Good toughness

   The steel-framed polyethylene plastic composite pipe has a moderate elastic modulus, which is 4 times that of polyethylene pipes and one-sixtieth that of steel pipes, indicating that the product has moderate toughness and inherits the characteristics of polyethylene flexible pipes, which is convenient for Excavation construction and slope laying, reduce construction costs.

Parameters

Spec	Nominal Pressure/MPA
	1.0MPA	1.6MPA	2.0MPA	2.5MPA	3.5MPA
	Thickness(mm)	Thickness(mm)	Thickness(mm)	Thickness(mm)	Thickness(mm)
DN50		50X5.0	50X5.0	50X6.0	50X6.5
DN63		63X5.5	63X6.0	63X6.5	63X7.0
DN75		75X6.0	75X6.0	75X7.0	75X7.5
DN90		90X6.5	90X7.0	90X7.5	90X8.0
DN110	110X6.0	110X7.0	110X7.5	110X8.0	110X8.5
DN140	140X6.0	140X8.0	140X8.5	140X9.5	140X9.5
DN160	160X6.5	160X9.0	160X9.5	160X10.5	160X11.5
DN200	200X7.0	200X9.5	200X10.5	200X12.5
DN225	225X8.0	225X10.0	225X10.5
DN250	250X10.5	250X12	250X12
DN315	315X12	315X13
DN355	355X12.5	355X14
DN400	400X13	400X15
DN450	450X14	450X16
DN500	500X16	500X18
DN560	560X20	560X21
DN630	630X23	630X24
